Description:

A powerful air-cooled engine with EFI technology delivers a responsive, fuel efficient performance. This mower provides powerful acceleration and throttle response. Built-in diagnostics and service light on the instrument panel simplify troubleshooting.

• Type: Collection
• Power: 26.5 HP
• Engine: Kohler EFI
• Ideal Application:
• Commercial Properties, Multi-Unit Complexes
• Key Attributes: Compact, Agile, Versatile
• Decks: 7 Collection, 7 Discharge, 5 Mulching
• Popular Add-ons:
• Implement Hitch
• 48” Dozer Blade
• Two-Stage Snowblower
• Hi-Dump

Features:

Fully Synthetic Oil

• Uses Kohler Pro 300-Hour Extended Life Oil and Filter for optimal engine performance and longevity.

Transmission Oil

• Equipped with a Performance System that enhances drivetrain protection and performance.

Agile

• Emphasizes responsiveness and profitability, likely highlighting the efficiency and maneuverability of the equipment.

Walker T23 Non-Collection

• Offers a non-collection option, providing flexibility for various lawn care preferences and conditions.

Specification:

Engine

• Kohler CH680 (Carbureted)
• Kohler ECH749 (Electronic Fuel Injection - EFI)

Fuel System

• Carburetor for Kohler CH680
• EFI for Kohler ECH749

Cooling System

• Air-cooled for both engines

Displacement

• Kohler CH680: 674 cc (41.1 cu. in.)
• Kohler ECH749: 747 cc (45.6 cu. in.)

Maximum Power

• Kohler CH680: 22.5 HP @ 3600 RPM
• Kohler ECH749: 26.5 HP @ 3600 RPM

Maximum Torque

• Kohler CH680: 36.6 ft-lbs
• Kohler ECH749: 40 ft-lbs

Fuel Capacity

• 4.7 gallons (17.8 liters) for both engine options

Seat

• Comfort Seat provided for ergonomic support

Weight

• Kohler CH680:
• Dry Weight: 820 lbs (372 kg)
• Operating Weight: 1039 lbs (471 kg)
• Kohler ECH749:
• Dry Weight: 815 lbs (370 kg)
• Operating Weight: 1034 lbs (469 kg)

Dimensions

• Height: 50 inches (127 cm)
• Width: 49.25 inches (125 cm)
• Length:
• Kohler CH680: 93.25 inches (237 cm)
• Kohler ECH749: 93 inches (236 cm)
